GT20 Max Ebike
torque 120N.m, can climb 35 degrees slope, fat tire motorcycle ebike
GT20 MAX Specifications
Performance
- Top Speed: Class 2/3, 40 Mph (65Km/h)
- Range: 80+miles (128km) in Class-2 throttle-only mode (pure electricity); 145miles (233km) in Class-1 PAS (pedal assist)
- Motor: 60V Peak 2000W (Rated 1500W) Brushless Rear Hub Motor 120N.m
- Battery: 60V 25Ah+15Ah Samsung Battery (Lithium 18650 Cells)
- Energy: 2400Wh
- Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel
- Rear Suspension: 850 Pounds, 180mm Travel
- Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc
- Tires: ARISUN Off Road Tire 20" × 4.0" A820 60TPI with Meimeng Tire+PVC Line
- Throttle: Thumb Throttle
Electronics
- Charger: 60V5A Charger
- Charging Time: 3.5-8.0 Hours
- Display: Easy Read LCD Display
- Controller: 60V 35A
- Front Light: Classic Angel Eye Headlight, 120 LUX
- Rear Light: LED
- Pedal Assist: 3 Levels
- Sensors: Speed Sensor
Components
- Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
- Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
- Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
- Rear Derailleur: Shimano 7-Speed
- Chain: 7-speed Anti-rust, 1/2" * 3/32"
- Handlebars: Split Handlebar, φ32 φ22 Sand Black
Geometry
- Suitable Height: 5'1" - 6'5"
- Seat Height: 32.6" (83cm)
- Bike Height: 41.7" (106cm)
- Wheelbase: 47.8" (121.5cm)
- Handlebar Width: 27.2" (69cm)
- Bike Weight: ≥99lbs (with Battery) (≥45kg)
- Maximum Load: 330lbs (150kg)
- Safe Load: 265lbs (120kg)
- Overall Size: 70.9" * 27.2" *41.7" (180*69*106cm)
- Package Size: 59.4" * 13.8" * 36.2" (151*35*92cm)
The rear suspension has 3 holes for 3 levels of height adjustment, allowing you to adjust to a comfortable riding height.
80mm front suspension travel, 180mm rear suspension travel, 850 lbs.
Front and rear double-piston hydraulic oil brakes, equipped with 180MM brake discs, make riding safer.
The GT20 MAX comes standard with a rear rack and rearview mirror.
Brand new waterproof and rust-proof chain, silver-white.
The crank adopts a double cover chain design, which effectively reduces the risk of chain dropping and makes you ride more safely.
Flowing headlights, LED taillights, and flowing turn signals illuminate your way forward.
The all-aluminum frame has undergone 10,000 collision tests and is sturdy and reliable.
The rear suspension has 3 holes for 3 levels of height adjustment, allowing you to adjust to a comfortable riding height.
80mm front suspension travel, 180mm rear suspension travel, 850 lbs.
Front and rear double-piston hydraulic oil brakes, equipped with 180MM brake discs, make riding safer.
The GT20 MAX comes standard with a rear rack and rearview mirror.
Brand new waterproof and rust-proof chain, silver-white.
The crank adopts a double cover chain design, which effectively reduces the risk of chain dropping and makes you ride more safely.
Flowing headlights, LED taillights, and flowing turn signals illuminate your way forward.
The all-aluminum frame has undergone 10,000 collision tests and is sturdy and reliable.
Support
Manual
Certificate
VIN Number
The VIN number (Serial number) of the GT20 MAX ebike is in the middle of the front fork of each GT20 MAX (please note that the VIN number of the GT20 MAX is unique and cannot be repeated)
Package
GT20 MAX Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1/Rear Shelf*1/Rearview Mirror*1
The VIN number (Serial number) of the GT20 MAX ebike is in the middle of the front fork of each GT20 MAX (please note that the VIN number of the GT20 MAX is unique and cannot be repeated)
GT20 MAX Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1/Rear Shelf*1/Rearview Mirror*1
Hello everyone, I purchased this model, as a daily transport to work and home. This model is truly extraordinary, comfort, stability, everything is thought out thoroughly, taking into account the price which is really a bargain, compared to the performance it offers on the road, it is incredibly breathtaking. I am the only one in my city who purchased this superb model, everyone is looking after it. I am extremely satisfied that I chose the most powerful model, speed, stability, 10 on the line, smart front light, I have no words. Thank you for giving me the opportunity to ride such a beauty of a bicycle.
I'm just adding some photos of mine bike coswheel GT 20 max
Hey I bought coswheel GT 20 max and it's nice bike the problem is only cover for display and front light,but in overall is strong 4.5 thanks
So first off let me say this is a great fun bike, I've already put 132.4 miles on my bike. I use this as a daily comuter bike and it definitely is a head turner. Now with that being said, I do have some complaints. First off, when the bike got to me the user manual that came with the product was for the base model of the coswheel gt20. So all the extra steps of how to install the extra battery, the mirrors, and the rack took longer than expected. As well as missing hardware for installing the back rack. Like I side with the wrong user manual it was also showing different parts than what actually came with the bike so there was confusion on how to put together. secondly, there is not even a downloadable pdf file for the correct user manual for the coswheel gt20 max anywhere on the Internet so it is very much trial and error of maintenance of this bike. The seat is slightly uncomfortable when riding and they only sent one charger for two batteries. Other than that this product is wonderful, just wish I could rate it higher.
My Honest Review After 3 Months
I bought this bike three months ago, and it has been extremely helpful. I can honestly say it’s a really cool ride — the accelerator is smooth, the brakes work perfectly, and it feels just like a motorcycle. It definitely turns heads wherever I go, and the build quality is solid. I’ve received a lot of positive comments from people around me.
One thing I would point out is that while many people would love to own a bike like this, the price might be a bit high for some. Also, I’ve seen other bikes around with built-in security alarms, which is something this model lacks. I think adding a security alarm would be a great improvement, especially since I can’t leave it outside without worrying about theft — it’s quite easy to steal without proper protection.
All in all, I highly recommend this bike. It’s a fantastic product, and with just a few upgrades like a security system, it would be perfect.
---
