CT20S EBIKE
torque 120N.m, can climb 35 degrees slope, fastest fat tire electric bike
What Online Reviewers Say CT20S
The CT20S ebike is favored by more and more customers, and many customers have posted their objective evaluations of the CT20S on YouTube.
CT20S Specifications
Performance
- Top Speed: Class 2/3, 28+ Mph (45+Km/h); Off-road Mode +++ (60V)
- Range: 55+miles (88km) in Class-2 throttle-only mode (pure electricity); 100+miles (161km) in Class-1 PAS (pedal assist)
- Motor: 60V Peak 2000W (Rated 1500W) Brushless Rear Hub Motor 120N.m
- Battery: 48V 35Ah Battery (Lithium 18650 Cells)
- Energy: 1650Wh
- Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel
- Rear Suspension: 180mm Travel
- Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc
- Tires: Off-road Tire 20" * 5.0" IA-2149 with AV+Lining
- Throttle: Grip Twist Throttle
Electronics
- Charger: 60V5A Charger
- Charging Time: 3.5-8.0 Hours
- Display: Easy Read LCD Display
- Controller: 48V 35A
- Front Light: Classic Angel Eye Headlight, 120 LUX
- Rear Light: LED
- Pedal Assist: 5 Levels
- Sensors: Speed Sensor
Components
- Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
- Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
- Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
- Rear Derailleur: Shimano 7-Speed
- Chain: 7-speed Anti-rust, 1/2" * 3/32"
- Handlebars: Sand Black 31.8*660
Geometry
- Suitable Height: 5'1" - 6'5"
- Seat Height: 33.4" (85cm)
- Bike Height: 45.3" (115cm)
- Wheelbase: 45.3" (115cm)
- Handlebar Width: 26.4" (67cm)
- Bike Weight: ≥88lbs (with Battery) (≥40kg)
- Maximum Load: 330lbs (150kg)
- Safe Load: 265lbs (120kg)
- Overall Size: 70.9" * 26.4" *45.3" (180*67*115cm)
- Package Size: 59.4" * 14.2" * 35.4" (151*36*90cm)
CT20S is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.
Equipped with double protection fenders, it is sturdy and durable, and the rear taillight LED is mounted on the fenders, making it look more luxurious.
Front and rear motorcycle-level dual-piston hydraulic oil brakes, equipped with 180MM high-quality brake discs, make your riding safer.
With soft and thick leather seat, make your ride more comfortable.
Both front and rear shock absorption, suspension travel 180MM, good resilience, so you are not afraid of any road.
CT20S is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.
Equipped with double protection fenders, it is sturdy and durable, and the rear taillight LED is mounted on the fenders, making it look more luxurious.
Front and rear motorcycle-level dual-piston hydraulic oil brakes, equipped with 180MM high-quality brake discs, make your riding safer.
With soft and thick leather seat, make your ride more comfortable.
Both front and rear shock absorption, suspension travel 180MM, good resilience, so you are not afraid of any road.
The CT20S is equipped with a high-speed brushless motor with a peak value of 2000W (rated at 1500W), with an instantaneous maximum current of 35AHand a torque of 120N.m (60V), allowing you to easily shuttle between cities and country roads.
CT20S provides two high-quality 18650 lithium battery options of 1650Wh (60V 27.5AH), with a battery life of up to 100miles (161KM). The maximum speed is 28+MPH (45+KM/H), off-road mode+++ (60V).
The CT20S LED display can be connected to an iPhone and Android (60V) to locate the ebike's position and view various parameters at any time. For specific details, please consult online customer service.
Customers And CT20S
Support
Manual
VIN Number
The VIN number (Serial number) of the CT20S ebike is in the middle of the front fork of each CT20S, as shown in the picture (please note that the VIN number of the CT20S is unique and cannot be repeated);
Package
CT20S Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1
The VIN number (Serial number) of the CT20S ebike is in the middle of the front fork of each CT20S, as shown in the picture (please note that the VIN number of the CT20S is unique and cannot be repeated);
CT20S Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1
Customer Reviews
I have the 60v version and I absolutely love it ! It’s been my work commuter and I can more or less keep up with traffic. I feel comfortable and safe riding it. Still learning and figuring everything out, but I’m definitely happy with my purchase. I get compliments on the bike all the time too!
i bought the ct20s looking for something fast and different. this bike is all of that and more. it is more than fast enough topping out over 40 mph and climbs hills with no issue. you will never see another person riding the same bike so people are always asking about it. the ct 20s is a rare bike. it is strongly built..nicely painted and uses pretty heavy duty parts for an ebike. the battery is powerful and pretty large....the bike is a good value for its price
Where can I get me one
I bought this bike and when I received it had some issues are not big deal, but the customer service and lunar the manager fixed everything to me. I got 44MPH by this bike and it is really worth every penny. I am from USA, I like this bike the most. This bike has very strong torque and the battery lives longer than any bike I have.
