R19 ELECTRIC DIRT BIKE
torque 120N.m, can climb 40 degrees slope, front 70/100-19 and rear 80/100-19 professional off-road wheelset.
R19 Specifications
Performance
- Top Speed: Class 2/3, 50 Mph (80Km/h)
- Range: 75+miles (120km) in Class-2 throttle-only mode (pure electricity); 145miles (200km) in Class-1 PAS (pedal assist)
- Motor: 72V Peak 6000W (Rated 3000W) Brushless Rear Hub Motor 120Nm
- Battery: 72V 40Ah Lithium Battery
- Energy: 2880Wh
- Front Suspension: Inverted hydraulic shock absorber with adjustable damping, 200mm Travel
- Rear Suspension: Adjustable Damping, 300mm Travel
- Front Brakes: Double piston hydraulic oil brake, Equipped with 220mm*2.8 brake disc
- Rear Brakes: Double piston hydraulic oil brake, Equipped with 180mm*2.8 brake disc
- Front Tires: 70/100-19 professional off-road tire
- Rear Tires: 80/100-19 professional off-road tire
- Throttle: Grip Twist Throttle
Electronics
- Charger: 84V6A Charger
- Charging Time: 6.0-7.0 Hours
- Display: 3.5" LCD high-brightness color screen
- Controller: 72V 80A
- Front Light: 12V Headlight
- Rear Light: LED
- Pedal Assist: 3 Levels
- Sensors: Speed Sensor
Components
- Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
- Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
- Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
- Rear Derailleur: Shimano 7-Speed
- Chain: 7-speed Anti-rust, 1/2" * 3/32"
- Handlebars: Split Handlebar, φ32 φ22 Sand Black
Geometry
- Suitable Height: 5'1" - 6'5"
- Seat Height: 32.6" (83cm)
- Bike Height: 41.7" (106cm)
- Wheelbase: 47.8" (121.5cm)
- Handlebar Width: 27.2" (69cm)
- Bike Weight: ≥99lbs (with Battery) (≥45kg)
- Maximum Load: 440lbs (200kg)
- Safe Load: 330lbs (150kg)
- Overall Size: 74.8" * 27.6" *43" (190*70*109cm)
The front and rear damping are adjustable, with 200mm travel at the front and 300mm travel at the rear.
Front and rear double-piston hydraulic oil brakes, with a 220mm*2.8 brake disc at the front and a 180mm*2.8 brake disc at the rear, make riding safer.
12V headlights and LED taillights illuminate your way forward.
The all-aluminum frame has undergone 10,000 collision tests and is sturdy and reliable.
The front and rear damping are adjustable, with 200mm travel at the front and 300mm travel at the rear.
Front and rear double-piston hydraulic oil brakes, with a 220mm*2.8 brake disc at the front and a 180mm*2.8 brake disc at the rear, make riding safer.
12V headlights and LED taillights illuminate your way forward.
The all-aluminum frame has undergone 10,000 collision tests and is sturdy and reliable.
Customers And R19
Support
Manual
Certificate
- UL2849 test report
- GCC certification
- GCC test report
- EU EN15194 and CE certification
- EU EN15194 and CE test report
VIN Number
The VIN number (Serial number) of the R19 ebike is in the middle of the front fork of each R19 (please note that the VIN number of the R19 is unique and cannot be repeated)
Package
R19 Ebike*1/Fender*2/Charger*1//Tool Bag*1
- UL2849 test report
- GCC certification
- GCC test report
- EU EN15194 and CE certification
- EU EN15194 and CE test report
The VIN number (Serial number) of the R19 ebike is in the middle of the front fork of each R19 (please note that the VIN number of the R19 is unique and cannot be repeated)
R19 Ebike*1/Fender*2/Charger*1//Tool Bag*1
