R19 Electric Dirt Bike

R19 frame is made of Hydroformed Triple-Butted 6061-T6 Aluminum Alloy, which is stronger and more reliable than other brands of iron frames, and is not easily corroded or aged. At the same time, our frames have undergone more than 10,000 collision tests to ensure your safety.

The R19 72V 40AH battery discharge port is made of high-quality technology, with a maximum discharge voltage of 84V, and is equipped with a 6A charger, which can be fully charged in 6-7 hours. The maximum range of a full charge is 124 miles (200km) (accelerator + pedal assist). If the speed is maintained at 25mph (40km/h), it is more friendly to the battery life.

The R19 rear suspension is equipped with a white 300mm adjustable damping shock absorber. The blue rotary button on the top can adjust the downward damping pressure, and the red rotary button on the bottom can adjust the upward damping pressure.

The front fork has an inverted hydraulic shock absorber with adjustable damping and 200mm suspension travel. By rotating the red button on the right, you can slowly adjust the oil pressure to adjust the damping, making the front suspension rebound slower or faster.

The R19 is equipped with a heavy-duty dual-piston hydraulic brake system, with a front wheel brake pad of 220mmX2.8 and a rear wheel brake pad of 180mmX2.8, providing heavy and stable brakes.

The front wheel 70/100-19M/C high-strength off-road tire and the rear wheel 80/100-19M/C high-strength off-road tire can easily cross gravel, mud and bumpy roads.

Place the NFC card that comes with the R19 below the 3.5" color display (the sensor is slightly below the display) to unlock the off-road electric bike. It should be noted that when the bike is just unlocked or the bike has been stationary for 3 seconds, the R19 will enter the neutral setting and display the "P" gear position, and the bike will not start when the throttle is twisted. You need to hold the brake handle tightly to resume the throttle.

After unlocking the R19 by placing the NFC card on the display, the throttle speed can be switched by increasing or decreasing the gear on the left handle. There are 3 gears to switch, and the maximum speed can reach 50mph (80km/h) in gear 3. After pressing and holding the top button for a few seconds, when the display shows "25km/h", it means that the R19 speed limit is 15mph (25km/h). After pressing and holding the top button again, when the display shows "99km/h", it means that the R19 speed limit is lifted and restored to 50mph (80km/h). Press the middle "M" button to switch the function of the display.

The R19 is equipped with a removable power supply. When you need to remove the battery, please unplug the discharge port on the battery and loosen the lock. When you put the battery back in, remember to lock the battery lock to prevent the battery from shaking during riding, which may cause danger.
