Top Speed: Class 2/3, 28 Mph (45Km/h) Range: 50+miles (80km) in Class-2 throttle-only mode (pure electricity); 87miles (140km) in Class-1 PAS (pedal assist) Motor: 48V Peak 1500W (Rated 1000W) Brushless Rear Hub Motor 80N.m Battery: 48V 25Ah Battery (Lithium 18650 Cells) Energy: 1200Wh Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc Tires: Off-road Tire 20" * 5.0" IA-2149 with AV+Lining Throttle: Grip Twist Throttle (Old) / Thumb Throttle (New)

Charger: 48V3A Charger Charging Time: 3.5-8.0 Hours Display: Easy Read LCD Display Controller: 48V 28A Front Light: Classic Angel Eye Headlight, 120 LUX Rear Light: LED Pedal Assist: 3 Levels Sensors: Speed Sensor

Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2 Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate Rear Derailleur: Shimano 7-Speed Chain: 7-speed Anti-rust, 1/2" * 3/32" Handlebars: Sand Black 31.8*660

Suitable Height: 5'1" - 6'5" Seat Height: 33.4" (85cm) Bike Height: 45.3" (115cm) Wheelbase: 45.3" (115cm) Handlebar Width: 26.4" (67cm) Bike Weight: ≥88lbs (with Battery) (≥40kg) Maximum Load: 330lbs (150kg) Safe Load: 265lbs (120kg) Overall Size: 70.9" * 26.4" *45.3" (180*67*115cm) Package Size: 59.4" * 14.2" * 35.4" (151*36*90cm)

CT20 EBIKE

Name: CT20 EBIKE
Brand: COSWHEEL
Price: 1699.0 USD
Availability: InStock
Rating: 5.0 (11 reviews)

torque 80N.m, can climb 30 degrees slope, family adult electric bike

$1,699.00

$1,899.00

Save $200.00

Quantity:

CT20 EBIKE

$1,699.00

$1,899.00

What Online Reviewers Say CT20

The CT20 ebike is favored by more and more customers, and many customers have posted their objective evaluations of the CT20 on YouTube.

CT20 Specifications

Performance

Top Speed: Class 2/3, 28 Mph (45Km/h)
Range: 50+miles (80km) in Class-2 throttle-only mode (pure electricity); 87miles (140km) in Class-1 PAS (pedal assist)
Motor: 48V Peak 1500W (Rated 1000W) Brushless Rear Hub Motor 80N.m
Battery: 48V 25Ah Battery (Lithium 18650 Cells)
Energy: 1200Wh
Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel
Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc
Tires: Off-road Tire 20" * 5.0" IA-2149 with AV+Lining
Throttle: Grip Twist Throttle (Old) / Thumb Throttle (New)

Electronics

Charger: 48V3A Charger
Charging Time: 3.5-8.0 Hours
Display: Easy Read LCD Display
Controller: 48V 28A
Front Light: Classic Angel Eye Headlight, 120 LUX
Rear Light: LED
Pedal Assist: 3 Levels
Sensors: Speed Sensor

Components

Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
Rear Derailleur: Shimano 7-Speed
Chain: 7-speed Anti-rust, 1/2" * 3/32"
Handlebars: Sand Black 31.8*660

Geometry

Suitable Height: 5'1" - 6'5"
Seat Height: 33.4" (85cm)
Bike Height: 45.3" (115cm)
Wheelbase: 45.3" (115cm)
Handlebar Width: 26.4" (67cm)
Bike Weight: ≥88lbs (with Battery) (≥40kg)
Maximum Load: 330lbs (150kg)
Safe Load: 265lbs (120kg)
Overall Size: 70.9" * 26.4" *45.3" (180*67*115cm)
Package Size: 59.4" * 14.2" * 35.4" (151*36*90cm)

Legitimate

US: It has passed the US UL2849 certification and can be shipped with a 750W logo affixed to the motor according to the laws of each state.

EU: At present, European customers have not reported any regulatory issues after riding. We have CE and COC certificates. The speed of bikes shipped to Europe will be limited to 25km/h when they leave the factory. After receiving the bike, you can contact us for guidance on lifting the speed limit. We can also send you a 250W logo to be affixed to the motor in accordance with European regulations.

Other Regions: Please consult us

01

7-Speed Gearing

CT20 is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.

02

USB Charging

There is a USB 1AH charging port under the CT20 display, which is convenient for you to charge your mobile phone with low battery when riding outdoors, ensuring your safety.

03

Oil Brake

Front and rear motorcycle-level dual-piston hydraulic oil brakes, equipped with 180MM high-quality brake discs, make your riding safer.

04

Flowing Headlights

Equipped with water-type headlights, the irradiation range is wider and farther.

05

Soft Seat

With soft and thick leather seat, make your ride more comfortable.

06

Rear Shelf

The whole system is equipped with a rear shelf as standard, which can carry people for travel, with a maximum load of 150KG(safety 120KG).

07

Upgraded Throttle Handle

In 2024, the new CT20 has upgraded the handlebar from Grip Twist Throttle to Thumb Throttle. A quick release function has been added to make it easier to replace accessories.

01

7-Speed Gearing

CT20 is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.

02

USB Charging

There is a USB 1AH charging port under the CT20 display, which is convenient for you to charge your mobile phone with low battery when riding outdoors, ensuring your safety.

03

Oil Brake

Front and rear motorcycle-level dual-piston hydraulic oil brakes, equipped with 180MM high-quality brake discs, make your riding safer.

04

Flowing Headlights

Equipped with water-type headlights, the irradiation range is wider and farther.

05

Soft Seat

With soft and thick leather seat, make your ride more comfortable.

06

Rear Shelf

The whole system is equipped with a rear shelf as standard, which can carry people for travel, with a maximum load of 150KG(safety 120KG).

07

Upgraded Throttle Handle

In 2024, the new CT20 has upgraded the handlebar from Grip Twist Throttle to Thumb Throttle. A quick release function has been added to make it easier to replace accessories.

Different Experience

The GT20 is equipped with a high-speed brushless motor with a peak value of 1500W (rated at 1000W), with an instantaneous maximum current of 28AH and a torque of 80N.m, allowing you to easily shuttle between cities and country roads.

Go Far Away Happily

GT20 provides 1200Wh (25AH) high-quality 18650 lithium battery with a range of up to 87 miles (140KM) and a max speed of 28MPH (45KM/H). It is legal and complies with Class 2 and Class 3 modes. Please feel free to ride.

Family Commuter Ebike

The CT20 is 180cm (70.9") long, with an extra-long body and 5" * 20" all-terrain tires. At the same time, it is equipped with a large storage rack under the frame, which is very suitable for a family's commuting and camping.

Customers And CT20

An outstanding electric bike on every level!

The Coswheel CT20 is simply exceptional. Powerful, comfortable, and with a futuristic design, it perfectly combines performance and style. The battery range is impressive, even on long rides, and the ride quality is incredibly smooth—whether in the city or on rougher paths. I was pleasantly surprised by the build quality and the sturdiness of the frame. All of this at a very affordable price compared to other models on the market.
Special thanks to Emerald from the technical support team, who was super responsive and very professional in answering my questions. Riding this bike every day is a real pleasure—it even turns heads wherever I go. Definitely an investment I don’t regret!

Look atypique, accélération dingue, tenue de route au top même à 2

Super vélo, rien à redire, meilleur rapport qualité/look/prix sur le marché du fatbike. Je recommande vivement. Arrivée sur palette bien emballé. Selle un peu dure mais franchement, ça le fait ! La seule chose à dire : dommage qu'il n'est pas d'amortisseur à l'arrière... Mais sinon je m'éclate avec ce bike !
